Multi-Station Prep Station
Description
This multi-station prep station focus on dealing with sanding dust and other debris generated from production. It can also guarantee safe production. The China preparation station has recycle system with pulse filter, takes small location, has high recycle efficiency and easy to clean.Features
1. Multi-station prep station can improve working efficiency and it is time saving. It can repair many cars at the same time.2. Independent structure and its recycle adopt integrated combination design. It has the characters of compact design and small locations.
3. Multi-station prep station can meet different needs of the repair.
4. The recycle system of China preparation station has short distance, so there is no need to worry about cleaning pipes. It also reduces recycling pressure loss.
5. Its main functions are remove dust and waste air from maintenance workshop and polishing workshop to make sure the cleanness of working environment and improve maintenance quality.
6. The following spare parts of China preparation station are optional: infrared lamp, heating system; basement, recovery system, Siemens motor and Siemens electric components.
Parameters of Multi-Station Prep Station
| Outside Dimension | 7550×3550×3100mm(L×W×H) |
| Inside Dimension | 6300×3450×2650mm(L×W×H) |
| Plenum Dimension | 6300×3450×450mm(L×W×H) |
| Basement | No basement, 2 rows of pits for exhausting |
| Room Body | Back side with 50mm EPS wallboard, the other 3 sides with PVC curtains |
| Light System | Ceiling lights 8units×4pcs=32pcs×36W, with electronic ballasts |
| Generator Cabinet | Exhaust from rear side; square steel frame, galvanized steel cover |
| Intake and Exhaust System | 1 unit 5.5KW double intake centrifugal fan, model YDW-4.5S, air capacity: 15500 m 3/h, electric damper for exhausting |
| Purification System | Pre-filter, high efficiency filter, exhaust fiberglass filter |
| Roof | Galvanized steel plates |
| Control System | Fan operation switch, lighting switch, emergency stop |
| Install Way | Suspending steel hook from roof of building or steel column supporting |
| Total Power | 6.7KW |
